JBM-650
Cast Bronze Bearings with Graphite Plugs
Features & Benefits
The JBM-650 is a heavy-duty self-lubricating bearing system designed for extreme operating conditions where oil film maintenance is difficult or impossible. It combines the high load-carrying capacity of a cast bronze alloy with the low-friction properties of embedded solid lubricants. This bearing provides maintenance-free operation, excellent wear resistance, and superior corrosion protection. It is particularly effective in low-speed, high-load applications involving reciprocating, oscillating, or intermittent motion, and can withstand a wide temperature range from -40°C to +300°C (depending on lubricant type).
Structure
| Layer | Material | Thickness | Function |
|---|---|---|---|
| Cast Bronze Base with Solid Lubricant Plugs | Solid Cast | The structure consists of a strong cast bronze-based metal matrix acting as the load-bearing component, with special solid lubricants (such as Graphite or PTFE+MoS2) embedded as plugs. During operation, these plugs transfer a solid lubricant film to the mating surface, enabling self-lubrication without the need for external oil or grease. |
Technical Data
base material grade 650
- material CuZn25Al5Mn4
- density 7.8 g/cm³
- hardness ≥ HB210
- tensile strength ≥ 750 N/mm²
- yield strength ≥ 450 N/mm²
- elongation ≥ 12%
- coefficient of linear expansion 1.9×10⁻⁵/℃
performance limit
- max load 50 MPa (Standard) / up to 100 MPa (Grade 650W3)
- max speed dry 0.5 m/s
- max speed lubricated 1.0 m/s
- max pv dry 1.65 N/mm²*m/s
- max pv lubricated 3.25 N/mm²*m/s
- temperature limit -40℃ ~ +300℃ (Standard)
available solid lubricants
- SL1 Graphite based (Temp limit 400℃) - Suit for general machines and atmosphere
- SL4 PTFE + MoS2 based (Temp limit 300℃) - Suit for water/sea lubrication
Typical Applications
Construction & Heavy Equipment
The JBM-650 is engineered for rigorous environments found in steel metallurgy (rollers), mining machinery, and successive casting machines.
Learn More
Oil & Gas
It is a critical component in water engineering projects such as dam gates and hydraulic turbines, as well as in marine applications like ships and turbo generators where corrosion resistance is paramount.
Learn More
Automotive
Widely used in automotive production lines, injection molding machines, and plastic industry equipment due to its ability to handle high pressures and intermittent oscillating motions.
